VBSpam Comparative Review March 2018

Martijn Grooten & Ionuţ Răileanu

Virus Bulletin

Copyright © Virus Bulletin 2018




Introduction

'Don't open email attachments or click on links in emails from strangers' – this is a common piece of security advice which, if followed to the letter, would prevent a lot of malware infections. However, the piece of advice ignores two important points: first, that authenticating the source of an email (and thus determining whether it came from a stranger) is notoriously hard for an untrained user. And second, that email attachments are meant to be opened and links in emails are meant to be clicked.

From phishing awareness training to better user interfaces in email clients, there are many things an organization can do to reduce the risk of a malware infection via email. If done right, such measures could have a significant long-term impact.

Still, one would want to avoid the situation where users have to make a decision several times a day as to whether or not to trust an email. That is why email security products (or spam filters) have such an important task and, in general, they do a good job of blocking such malicious emails.

Yet, as shown in this report, while catch rates of malicious and non-malicious spam may be very high, some emails with a malicious payload still manage to bypass several products.

In this test, 11 full email security products were lined up on the Virus Bulletin test bench, as well as eight blacklists of various kinds. Each of the 11 full products reached the required standard to achieve a VBSpam award, and six of them performed so well they achieved a VBSpam+ award.



Using a monkey to get malware into the inbox

In this test, all but one of the participating full products blocked all emails with a malicious attachment1, showing how well email security products perform when it comes to keeping most malicious attachments out of users' inboxes.

But attachments aren't the only way for malware to spread via emails. Another method is to use links. Emails that contain such links tend to be blocked widely as well; delivering emails simply scales very badly, especially if the emails are unwanted or malicious.

However, sometimes spammers find a way around this. Recently, there have been a number of malicious email campaigns that have used the infrastructure of MailChimp, a popular email service provider used by many legitimate organizations to send newsletters2. Thanks to MailChimp's respectable reputation – both in terms of its brand and in terms of the cleanliness of its IP space and its domains – the emails sent via its servers are not as likely to be blocked as regular malicious spam, sent from botnets, would be.

Indeed, among the spam emails most commonly missed by the participating products were a few dozen emails sent through MailChimp and with an apparent malicious payload. We say 'apparent' as the links had been taken down by the time we analysed the emails. However, circumstantial evidence suggests that, at the time of delivery, these links pointed to active malware.

Credit goes to the OnlyMyEmail and Bitdefender products, both of which blocked all of these malicious emails.



Results

Though spam catch rates continued to be very high overall, for most products they were lower than they had been in the last test; the MailChimp campaign is a good illustration of that.

Once again, OnlyMyEmail achieved the highest catch rate, missing only six spam emails, none of which appeared to be malicious. All other products missed at least 40 spam emails.

Six products combined a spam catch rate of 99.5% or higher with a complete absence of false positives in the ham set, and a low false positive rate in the 'newsletter' category. These products – Bitdefender, ESET, FortiMail, IBM and both Kaspersky products – each earned a VBSpam+ award.

New in this test report is Zetascan, whose Zetascan Query Service aggregates various IP- and domain-based blacklists. Since Zetascan isn't exposed to the full emails, we consider it a partial solution (indeed, it is intended to be integrated into an existing solution).



Axway MailGate 5.5.1

SC rate: 99.44%
FP rate: 0.01%
Final score: 99.25
Project Honey Pot SC rate: 99.37%
Abusix SC rate: 99.59%
Newsletters FP rate: 3.3%
Malware SC rate: 93.61%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% speed-colour-blobs-ORANGE.jpg



VBSpam





Bitdefender Security for Mail Servers 3.1.6

SC rate: 99.93%
FP rate: 0.00%
Final score: 99.90
Project Honey Pot SC rate: 99.96%
Abusix SC rate: 99.86%
Newsletters FP rate: 0.7%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam+





ESET Mail Security for Microsoft Exchange Server

SC rate: 99.95%
FP rate: 0.00%
Final score: 99.95
Project Honey Pot SC rate: 99.97%
Abusix SC rate: 99.90%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam+





Forcepoint Email Security Cloud

SC rate: 98.81%
FP rate: 0.12%
Final score: 98.16
Project Honey Pot SC rate: 98.71%
Abusix SC rate: 99.02%
Newsletters FP rate: 0.7%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam





Fortinet FortiMail

SC rate: 99.86%
FP rate: 0.00%
Final score: 99.86
Project Honey Pot SC rate: 99.99%
Abusix SC rate: 99.60%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam+





IBM Lotus Protector for Mail Security

SC rate: 99.93%
FP rate: 0.00%
Final score: 99.93
Project Honey Pot SC rate: 99.96%
Abusix SC rate: 99.88%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam+





Kaspersky for Exchange

SC rate: 99.93%
FP rate: 0.00%
Final score: 99.93
Project Honey Pot SC rate: 99.96%
Abusix SC rate: 99.87%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam+





Kaspersky Linux Mail Security 8.0

SC rate: 99.93%
FP rate: 0.00%
Final score: 99.93
Project Honey Pot SC rate: 99.96%
Abusix SC rate: 99.87%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam+





Libra Esva 4.1.0.0

SC rate: 99.80%
FP rate: 0.01%
Final score: 99.73
Project Honey Pot SC rate: 99.92%
Abusix SC rate: 99.55%
Newsletters FP rate: 0.0%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% speed-colour-blobs-YELLOW.jpg



VBSpam





OnlyMyEmail's Corporate MX‑Defender

SC rate: 99.99%
FP rate: 0.06%
Final score: 99.68
Project Honey Pot SC rate: 99.99%
Abusix SC rate: 99.99%
Newsletters FP rate: 1.1%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam





ZEROSPAM

SC rate: 99.64%
FP rate: 0.00%
Final score: 99.55
Project Honey Pot SC rate: 99.70%
Abusix SC rate: 99.51%
Newsletters FP rate: 2.6%
Malware SC rate: 100.00%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN



VBSpam





IBM X-Force Combined

SC rate: 95.63%
FP rate: 0.03%
Final score: 95.49
Project Honey Pot SC rate: 95.42%
Abusix SC rate: 96.05%
Newsletters FP rate: 0.0%
Malware SC rate: 86.30%





IBM X-Force IP

SC rate: 83.83%
FP rate: 0.01%
Final score: 83.76
Project Honey Pot SC rate: 78.65%
Abusix SC rate: 94.52%
Newsletters FP rate: 0.0%
Malware SC rate: 86.30%





IBM X-Force URL

SC rate: 84.96%
FP rate: 0.01%
Final score: 84.89
Project Honey Pot SC rate: 86.39%
Abusix SC rate: 82.01%
Newsletters FP rate: 0.0%
Malware SC rate: 31.51%





Spamhaus DBL

SC rate: 33.04%
FP rate: 0.00%
Final score: 33.04
Project Honey Pot SC rate: 46.16%
Abusix SC rate: 5.98%
Newsletters FP rate: 0.0%
Malware SC rate: 31.96%





Spamhaus ZEN

SC rate: 84.46%
FP rate: 0.00%
Final score: 84.46
Project Honey Pot SC rate: 79.27%
Abusix SC rate: 95.15%
Newsletters FP rate: 0.0%
Malware SC rate: 84.93%





Spamhaus ZEN+DBL

SC rate: 92.42%
FP rate: 0.00%
Final score: 92.42
Project Honey Pot SC rate: 90.81%
Abusix SC rate: 95.72%
Newsletters FP rate: 0.0%
Malware SC rate: 85.84%





URIBL

SC rate: 35.55%
FP rate: 0.00%
Final score: 35.55
Project Honey Pot SC rate: 47.80%
Abusix SC rate: 10.28%
Newsletters FP rate: 0.0%
Malware SC rate: 31.05%





Zetascan

SC rate: 79.81%
FP rate: 0.21%
Final score: 78.71
Project Honey Pot SC rate: 72.40%
Abusix SC rate: 95.08%
Newsletters FP rate: 1.9%
Malware SC rate: 47.03%





Results tables

  True negatives False positives FP rate False negatives True positives SC rate VBSpam Final score
Axway 7245 1 0.01% 451 80423 99.44% VBSpam 99.25
Bitdefender 7246 0 0..00% 58 80816 99.93% VBSpam+ 99.90
ESET 7246 0 0.00% 42 80832 99.95% VBSpam+ 99.95
Forcepoint 7237 9 0.12% 964 79910 98.81% VBSpam 98.16
FortiMail 7246 0 0.00% 111 80763 99.86% VBSpam+ 99.86
IBM Lotus Protector 7246 0 0.00% 54 80820 99.93% VBSpam+ 99.93
Kaspersky for Exchange 7246 0 0.00% 56 80818 99.93% VBSpam+ 99.93
Kaspersky LMS 7246 0 0.00% 56 80818 99.93% VBSpam+ 99.93
Libra Esva 7245 1 0.01% 162 80712 99.80% VBSpam 99.73
OnlyMyEmail 7242 4 0.06% 6 80868 99.99% VBSpam 99.68
ZEROSPAM 7246 0 0.00% 290 80584 99.64% VBSpam 99.55
IBM X-Force Combined* 7244 2 0.03% 3534 77340 95.63% N/A 95.49
IBM X-Force IP* 7245 1 0.01% 13076 67798 83.83% N/A 83.76
IBM X-Force URL* 7245 1 0.01% 12164 68710 84.96% N/A 84.89
Spamhaus DBL* 7246 0 0.00% 54151 26723 33.04% N/A 33.04
Spamhaus ZEN* 7246 0 0.00% 12571 68303 84.46% N/A 84.46
Spamhaus ZEN+DBL* 7246 0 0.00% 6133 74741 92.42% N/A 92.42
URIBL* 7246 0 0.00% 52127 28747 35.55% N/A 35.55
Zetascan* 7231 15 0.21% 16331 64543 79.81% N/A 78.71

*The IBM X-Force, Spamhaus, URIBL and Zetascan products are partial solutions and their performance should not be compared with that of other products. (Please refer to the text for full product names and details.)



  Newsletters Malware Project Honey Pot Abusix STDev Speed
False positives FP rate False negatives SC rate False negatives SC rate False negatives SC rate 10% 50% 95% 98%
Axway 9 3.3% 14 93.61%   342 99.37%  109 99.59%  1.09 Green Green Green speed-colour-blobs-ORANGE.jpg
Bitdefender 2 0.7% 0 100.00% 20 99.96%  38 99.86%  0.24 Green Green Green Green
ESET 0 0.0% 0 100.00% 15 99.97%  27 99.90%  0.28 Green Green Green Green
Forcepoint 2 0.7% 0 100.00% 704  98.71% 260 99.02%  1.76 Green Green Green Green
FortiMail  0 0.0% 0 100.00% 5 99.99%  106 99.60%   0.51 Green Green Green Green
IBM 0  0.0%  0 100.00%  22 99.96%  32 99.88%  0.37 Green Green Green Green
Kaspersky for Exchange  0  0.0%  0  100.00%  21 99.96%   35 99.87%  0.41 Green Green Green Green
Kaspersky LMS  0  0.0%  0  100.00%  22 99.96%   34 99.87%  0.41 Green Green Green Green
Libra Esva  0  0.0%  0  100.00% 43 99.92%  119 99.55%  0.84 Green Green Green speed-colour-blobs-YELLOW.jpg
OnlyMyEmail 3 1.1%  0  100.00%  3 99.99%  3 99.99%  0.05 Green Green Green Green
ZEROSPAM  7 2.6%  0  100.00%  161 99.70%  129 99.51%  1.65 Green Green Green Green
IBM X-Force Combined*  0 0.0% 30 86.30%  2492  95.42% 1042  96.05% 8.68  N/A N/A N/A N/A
IBM X-Force IP*  0  0.0%  30 86.30%  11628   78.65%  1448 94.52% 10.48  N/A N/A N/A N/A
IBM X-Force URL*  0  0.0%  150 31.51%  7414  86.39%  4750 82.01% 12.79  N/A N/A N/A N/A
Spamhaus DBL*  0  0.0% 149 31.96%  29324  46.16% 24827  5.98% 13.69  N/A N/A N/A N/A
Spamhaus ZEN*  0  0.0% 33 84.93%  11290  79.27% 1281  95.15%  9.51 N/A N/A N/A N/A
Spamhaus ZEN+DBL*  0  0.0%  31 85.84%  5003 90.81%  1130 95.72%  6.49 N/A N/A N/A N/A
URIBL*  0 0.0% 151 31.05%  28435  47.80% 23692   10.28% 14.48  N/A N/A N/A N/A
Zetascan*  5 1.9%  116 47.03%  15031  72.40% 1300 95.08%  9.72  N/A N/A N/A N/A

*The Spamhaus products, IBM X-Force and URIBL are partial solutions and their performance should not be compared with that of other products. None of the queries to the IP blacklists included any information on the attachments; hence their performance on the malware corpus is added purely for information.
The standard deviation of a product is calculated using the set of its hourly spam catch rates.
0–30 seconds; 30 seconds to two minutes; two minutes to 10 minutes; more than 10 minutes.
(Please refer to the text for full product names.)



Hosted solutions Anti-malware IPv6 DKIM SPF DMARC Multiple MX-records Multiple locations
Forcepoint Forcepoint Advanced Malware Detection
OnlyMyEmail Proprietary (optional)   *
ZEROSPAM ClamAV

* OnlyMyEmail verifies DMARC status but doesn't provide feedback at the moment.
(Please refer to the text for full product names.)



Local solutions Anti-malware IPv6 DKIM SPF DMARC Interface
CLI GUI Web GUI API
Axway MailGate Kaspersky, McAfee
Bitdefender Bitdefender
ESET ESET Threatsense
FortiMail Fortinet
IBM Sophos; IBM Remote Malware Detection
Kaspersky for Exchange Kaspersky Lab
Kaspersky LMS Kaspersky Lab
Libra Esva ClamAV; others optional

 (Please refer to the text for full product names.)



Products ranked by final score
ESET 99.95
IBM 99.93
Kaspersky for Exchange 99.93
Kaspersky LMS 99.93
Bitdefender 99.90
FortiMail 99.86
Libra Esva 99.73
OnlyMyEmail 99.68
ZEROSPAM 99.55
Axway 99.25
Forcepoint 98.16

 (Please refer to the text for full product names.)






Conclusion

This VBSpam report once again shows how well various products block unwanted and sometimes malicious emails. Yet, it also shows that some emails, even some with a malicious payload, managed to bypass several products. In the fight against malware spammers, we are winning the battle, but it's certainly not 'game over'.

Via the VBSpam tests we will continue to provide participants – including several that are tested privately – with feedback on their products' performance against various kinds of malicious emails. In the coming weeks and months, there is likely to be a lot of focus on those emails with a malicious attachment or link.

The next test report, which is to be published in June 2018, will continue to look at all aspects of spam. Those interested in submitting a product are asked to contact martijn.grooten@virusbulletin.com.



Appendix: set-up, methodology and email corpora

The full VBSpam test methodology can be found at https://www.virusbulletin.com/testing/vbspam/vbspam-methodology/.

The test ran for 16 days, from 12am on 10 February to 12am on 26 February 2018.

The test corpus consisted of 88,390 emails. 80,874 of these were spam, 54,468 of which were provided by Project Honey Pot, with the remaining 26,406 spam emails provided by spamfeed.me, a product from Abusix. There were 7,246 legitimate emails ('ham') and 270 newsletters.

Moreover, 219 emails from the spam corpus were found to contain a malicious attachment; though we report separate performance metrics on this corpus, it should be noted that these emails were also counted as part of the spam corpus.

Emails were sent to the products in real time and in parallel. Though products received the email from a fixed IP address, all products had been set up to read the original sender's IP address as well as the EHLO/HELO domain sent during the SMTP transaction, either from the email headers or through an optional XCLIENT SMTP command3. Consequently, products were able to filter email in an environment that was very close to one in which they would be deployed in the real world.

For those products running in our lab, we ran them as virtual machines on a VMware ESXi cluster. As different products have different hardware requirements – not to mention those running on their own hardware, or those running in the cloud – there is little point comparing the memory, processing power or hardware the products were provided with; we followed the developers' requirements and note that the amount of email we receive is representative of that received by a small organization.

Although we stress that different customers have different needs and priorities, and thus different preferences when it comes to the ideal ratio of false positives to false negatives, we created a one-dimensional 'final score' to compare products. This is defined as the spam catch (SC) rate minus five times the weighted false positive (WFP) rate. The WFP rate is defined as the false positive rate of the ham and newsletter corpora taken together, with emails from the latter corpus having a weight of 0.2:

WFP rate = (#false positives + 0.2 * min(#newsletter false positives , 0.2 * #newsletters)) / (#ham + 0.2 * #newsletters)

Final score = SC - (5 x WFP)

In addition, for each product, we measure how long it takes to deliver emails from the ham corpus (excluding false positives) and, after ordering these emails by this time, we colour-code the emails at the 10th, 50th, 95th and 98th percentiles:

YELLOW (yellow) = 30 seconds to two minutes



Products earn VBSpam certification if the value of the final score is at least 98 and the 'delivery speed colours' at 10 and 50 per cent are green or yellow and that at 95 per cent is green, yellow or orange.

Meanwhile, products that combine a spam catch rate of 99.5% or higher with a lack of false positives, no more than 2.5% false positives among the newsletters and 'delivery speed colours' of green at 10 and 50 per cent and green or yellow at 95 and 98 per cent earn a VBSpam+ award.



Footnotes

1DNS blacklists (also referred to as 'partial solutions') don't see the attachments and their performance on these emails is thus less relevant.

2https://www.virusbulletin.com/blog/2018/03/using-mailchimp-makes-malware-campaigns-little-bit-more-successful/.

3http://www.postfix.org/XCLIENT_README.html.

Download PDF




Latest reviews:

VB100 Comparative Review - April 2018

In the last of the current style VB100 tests, we put 35 anti-virus products from 32 vendors through their paces. 27 products achieved VB100 certification.

VBWeb Comparative Review - Spring 2018

In the latest VBWeb test we checked products against 571 drive-by downloads (exploit kits) and 423 direct malware downloads, as well as 335 URLs that we deemed ‘potentially malicious’.

VBSpam Comparative Review - March 2018

In this VBSpam test we looked at 11 full email security products as well as eight blacklists of various kinds. Each of the 11 full products reached the required standard to achieve a VBSpam award, and six of them performed so well they achieved a…

VB100 Comparative Review - February 2018

In the more than 20 years that Virus Bulletin’s anti-malware tests have been running, their primary aim has been to verify that products are able to keep up with the latest, confirmed threats. On this occasion, we were able to do this for no fewer…

VB100 Comparative Review - December 2017

At the end of this, the last VB100 test of 2017, 31 products from 27 vendors were able to add a VB100 award to their tallies.

We have placed cookies on your device in order to improve the functionality of this site, as outlined in our cookies policy. However, you may delete and block all cookies from this site and your use of the site will be unaffected. By continuing to browse this site, you are agreeing to Virus Bulletin's use of data as outlined in our privacy policy.
