VBSpam Email Security Comparative Review March 2019

Martijn Grooten & Ionuţ Răileanu

Virus Bulletin

Copyright © 2019 Virus Bulletin




Introduction

In this test – which forms part of Virus Bulletin's continuously running security product test suite – 11 full email security solutions and seven blacklists of various kinds were assembled on the test bench to measure their performance against various streams of wanted, unwanted and malicious emails.

The news in these VBSpam test reports tends to be good: email security products are an important first line of defence against the many email-borne threats and, particularly against the bulk of opportunistic threats, they perform really well. The news in this report is no exception, with all 11 full solutions obtaining a VBSpam award and four of them performing well enough to earn a VBSpam+ award.

However, it is important to look beyond the spam catch rates: block rates of malware and phishing emails, though still high, were significantly lower than the block rates of ordinary spam emails.



Malware and phishing

This test sees the debut of the 'phishing' subcategory of emails. Phishing in this context covers emails containing links that either lead to a site with a fake login page (traditional phishing) or that download malware. The reason for grouping these two types together reflects the fact that, for an email security product, the distinction often isn't clear.

Both emails that contain malware and phishing emails are sent in much smaller batches than traditional spam emails. While this means they won't contribute much to the overall spam catch rate, it also means that the campaigns are far more likely to stay under the radar. This is even more the case with phishing than it is with malware, because the 'maliciousness' in phishing emails isn't part of the email itself and thus often can't be considered during the filtering process.1

On our blog2, we have documented various recent examples of malware and phishing emails that were missed by some of the products in our lab. Looking at the phishing emails most commonly missed in this test, we see various traditional phishing scams targeting customers of banks, email and service providers, but also emails that link to malware such as Emotet.

Emotet was also one of the malware families regularly missed by a number of products when it was sent as an attachment to emails. The most widely missed email, however, was one that used the known method of attaching a Word document that is protected with a basic password – which prevents it from being scanned properly by anti-virus engines. Though the detection of malicious emails is about more than scanning the attachment, such non-detection does help the email to stay under the radar.



Results

Spam catch rates were once again high, with many products blocking 99.9% or more of the spam, but block rates of malware and phishing were significantly lower. All participating full solutions achieved a VBSpam award, and four vendors – Bitdefender, ESET, Fortinet and IBM – performed well enough to achieve a VBSpam+ award.

Fortinet, IBM and Libra Esva were the only products that didn't miss a single email with a malicious attachment; ESET was the only product not to miss a single phishing email.

New to the test bench on this occasion is Spamhaus Data Query Service, which is a quick and easy configuration of Apache SpamAssassin, the popular open-source spam filter, for subscribers to the Spamhaus Data Query Service. Indeed, the results of this test demonstrate that this simple set-up does a good job of blocking well over 99% of spam with few false positives.

The Abusix Mail Intelligence combined IP- and domain‑based blacklist is a continuation of Zetascan.



Axway MailGate 5.5.1

SC rate: 99.81%
FP rate: 0.10%
Final score: 99.31
Malware catch rate: 96.51%
Phishing catch rate: 94.46%
Project Honey Pot SC rate: 99.57%
Abusix SC rate: 99.87%
Newsletters FP rate: 0.5%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




Bitdefender Security for Mail Servers 3.1.7

SC rate: 99.98%
FP rate: 0.00%
Final score: 99.92
Malware catch rate: 99.13%
Phishing catch rate: 97.08%
Project Honey Pot SC rate: 100.00%
Abusix SC rate: 99.97%
Newsletters FP rate: 1.5%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




ESET Mail Security for Microsoft Exchange Server

SC rate: 99.99%
FP rate: 0.00%
Final score: 99.95
Malware catch rate: 98.69%
Phishing catch rate: 100.00%
Project Honey Pot SC rate: 99.99%
Abusix SC rate: 99.99%
Newsletters FP rate: 1.0%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




Fortinet FortiMail

SC rate: 99.95%
FP rate: 0.00%
Final score: 99.95
Malware catch rate: 100.00%
Phishing catch rate: 95.63%
Project Honey Pot SC rate: 99.99%
Abusix SC rate: 99.94%
Newsletters FP rate: 0.0%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




IBM Lotus Protector for Mail Security

SC rate: 99.93%
FP rate: 0.00%
Final score: 99.93
Malware catch rate: 100.00%
Phishing catch rate: 96.50%
Project Honey Pot SC rate: 99.96%
Abusix SC rate: 99.93%
Newsletters FP rate: 0.0%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




Kaspersky for Exchange

SC rate: 99.98%
FP rate: 0.02%
Final score: 99.89
Malware catch rate: 99.56%
Phishing catch rate: 99.42%
Project Honey Pot SC rate: 99.99%
Abusix SC rate: 99.98%
Newsletters FP rate: 0.0%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




Kaspersky Linux Mail Security 8.0

SC rate: 99.98%
FP rate: 0.02%
Final score: 99.89
Malware catch rate: 99.56%
Phishing catch rate: 99.42%
Project Honey Pot SC rate: 99.99%
Abusix SC rate: 99.98%
Newsletters FP rate: 0.0%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




Libra Esva 4.4.0.0

SC rate: 99.99%
FP rate: 0.04%
Final score: 99.76
Malware catch rate: 100.00%
Phishing catch rate: 98.83%
Project Honey Pot SC rate: 99.997%
Abusix SC rate: 99.98%
Newsletters FP rate: 1.0%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




Spamhaus Data Query Service

SC rate: 99.43%
FP rate: 0.02%
Final score: 99.34
Malware catch rate: 84.72%
Phishing catch rate: 60.06%
Project Honey Pot SC rate: 98.72%
Abusix SC rate: 99.63%
Newsletters FP rate: 0.0%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




Spin Safemail

SC rate: 99.93%
FP rate: 0.02%
Final score: 99.84
Malware catch rate: 99.56%
Phishing catch rate: 93.59%
Project Honey Pot SC rate: 99.94%
Abusix SC rate: 99.93%
Newsletters FP rate: 0.0%
Speed:

10% GREEN 50% GREEN 95% speed-colour-blobs-YELLOW.jpg 98% speed-colour-blobs-YELLOW.jpg




ZEROSPAM

SC rate: 99.92%
FP rate: 0.11%
Final score: 99.18
Malware catch rate: 99.13%
Phishing catch rate: 95.63%
Project Honey Pot SC rate: 99.97%
Abusix SC rate: 99.90%
Newsletters FP rate: 4.5%
Speed:

10% GREEN 50% GREEN 95% GREEN 98% GREEN




Abusix Mail Intelligence

SC rate: 97.12%
FP rate: 0.13%
Final score: 96.45
Malware catch rate: 89.08%
Phishing catch rate: 76.97%
Project Honey Pot SC rate: 87.15%
Abusix SC rate3: 99.82%
Newsletters FP rate: 0.0%



IBM X-Force Combined

SC rate: 98.03%
FP rate: 0.02%
Final score: 97.93
Malware catch rate: 71.62%
Phishing catch rate: 80.17%
Project Honey Pot SC rate: 96.83%
Abusix SC rate: 98.35%
Newsletters FP rate: 0.0%



IBM X-Force IP

SC rate: 96.92%
FP rate: 0.02%
Final score: 96.82
Malware catch rate: 70.31%
Phishing catch rate: 69.39%
Project Honey Pot SC rate: 93.69%
Abusix SC rate: 97.79%
Newsletters FP rate: 0.0%



IBM X-Force URL

SC rate: 67.57%
FP rate: 0.00%
Final score: 67.57
Malware catch rate: 3.49%
Phishing catch rate: 48.69%
Project Honey Pot SC rate: 87.89%
Abusix SC rate: 62.06%
Newsletters FP rate: 0.0%



Spamhaus DBL

SC rate: 47.75%
FP rate: 0.04%
Final score: 47.56
Malware catch rate: 1.31%
Phishing catch rate: 11.08%
Project Honey Pot SC rate: 36.09%
Abusix SC rate: 50.91%
Newsletters FP rate: 0.0%



Spamhaus ZEN

SC rate: 97.53%
FP rate: 0.00%
Final score: 97.53
Malware catch rate: 58.08%
Phishing catch rate: 27.99%
Project Honey Pot SC rate: 92.86%
Abusix SC rate: 98.80%
Newsletters FP rate: 0.0%



Spamhaus ZEN+DBL

SC rate: 97.92%
FP rate: 0.04%
Final score: 97.73
Malware catch rate: 58.95%
Phishing catch rate: 31.20%
Project Honey Pot SC rate: 94.06%
Abusix SC rate: 98.96%
Newsletters FP rate: 0.0%



Results tables

  True negatives False positives FP rate False negatives True positives SC rate Final score VBSpam
Axway 5221 5 0.10% 364 186799.2 99.81% 99.31 vbantispam-pass.gif
Bitdefender 5226 0 0.00% 44.2 187119 99.98% 99.92 vbantispam-plus.gif
ESET 5226 0 0.00% 23.6 187139.6 99.99% 99.95 vbantispam-plus.gif
FortiMail 5226 0 0.00% 89.2 187074 99.95% 99.95 vbantispam-plus.gif
IBM 5226 0 0.00% 124.2 187039 99.93% 99.93 vbantispam-plus.gif
Kaspersky for Exchange 5225 1 0.02% 36.6 187126.6 99.98% 99.89 vbantispam-pass.gif
Kaspersky LMS 5225 1 0.02% 33.6 187129.6 99.98% 99.89 vbantispam-pass.gif
Libra Esva 5224 2 0.04% 27.6 187135.6 99.99% 99.76 vbantispam-pass.gif
Spamhaus DQS 5225 1 0.02% 1060.6 186102.6 99.43% 99.34 vbantispam-pass.gif
Spin 5225 1 0.02% 126 187037.2 99.93% 99.84 vbantispam-pass.gif
ZEROSPAM 5220 6 0.11% 154.6 187008.6 99.92% 99.18 vbantispam-pass.gif
Abusix Mail Intelligence* 5219 7 0.13% 5396.6 181766.6 97.12% 96.45 N/A
IBM X-Force Combined* 5225 1 0.02% 3696.2 183467 98.03% 97.93 N/A
IBM X-Force IP* 5225 1 0.02% 5771.4 181391.8 96.92% 96.82 N/A
IBM X-Force URL* 5226 0 0.00% 60706 126457.2 67.57% 67.57 N/A
Spamhaus DBL* 5224   2 0.04% 97791.8  89371.4  47.75%  47.56 N/A
Spamhaus ZEN* 5226  0 0.00%  4619.4 182543.8  97.53%  97.53 N/A
Spamhaus ZEN+DBL* 5224   2 0.04%  3895.6 183267.6  97.92%  97.73  N/A

*The Abusix, IBM X-Force and Spamhaus ZEN/DBL products are partial solutions and their performance should not be compared with that of other products. (Please refer to the text for full product names and details.)



  Newsletters Malware Phishing Project Honey Pot Abusix STDev†
False positives FP rate False negatives SC rate False negatives SC rate False negatives SC rate False negatives SC rate
Axway 1 0.5% 8 96.51% 19 94.46% 173 99.57% 190.2 99.87% 0.30
Bitdefender 3 1.5% 2 99.13% 10 97.08% 0 100.00% 42.6 99.97% 0.11
ESET 2 1.0% 3 98.69% 0 100.00% 4 99.99% 18 99.99% 0.09
FortiMail 0 0.0% 0 100.00% 15 95.63% 2 99.99% 85.6 99.94% 0.17
IBM 0 0.0% 0 100.00% 12 96.50% 14.2 99.96% 108.4 99.93% 0.25
Kaspersky for Exchange 0 0.0% 1 99.56% 2 99.42% 4.6 99.99% 30.4 99.98% 0.13
Kapsersky LMS 0 0.0% 1 99.56% 2 99.42% 4.6 99.99% 27.4 99.98% 0.13
Libra Esva 2 1.0% 0 100.00% 4 98.83% 1.2 99.997% 24.8 99.98% 0.12
Spamhaus DQS 0 0.0% 35 84.72% 137 60.06% 510.2 98.72% 548.8 99.63% 0.71
Spin 0 0.0% 1 99.56% 22 93.59% 23 99.94% 101.4 99.93% 0.22
ZEROSPAM 9 4.5 2 99.13% 15 95.63% 11 99.97% 142 99.90% 0.25
Abusix Mail Intelligence* 0 0.0% 25 89.08% 79 76.97% 5127.4 87.15% 267.6 99.82% 1.71
IBM X-Force Combined* 0 0.0% 65 71.62% 68 80.17% 1265 96.83% 2429.6 98.35% 2.15
IBM X-Force IP* 0 0.0% 68 70.31% 105 69.39% 2515.8 93.69% 3254 97.79% 14.42
IBM X-Force URL* 0 0.0% 221 3.49% 176 48.69% 4832.2 87.89% 55872.2 62.06% 13.2
Spamhaus DBL* 0 0.0% 226 1.31% 305 11.08% 25493.6 36.09% 72296.6 50.91% 1.83
Spamhaus ZEN* 0 0.0% 96 58.08% 247 27.99% 2850.2 92.86% 1767.6 98.80% 1.71
Spamhaus ZEN+DBL* 0 0.0% 94 58.95% 236 31.20% 2367.6 94.06% 1526.4 98.96% 17.25

*The Abusix, IBM X-Force and Spamhaus ZEN/DBL products are partial solutions and their performance should not be compared with that of other products. None of the queries to the IP blacklists included any information on the attachments; hence their performance on the malware corpus is added purely for information.
† The standard deviation of a product is calculated using the set of its hourly spam catch rates.
(Please refer to the text for full product names and details.)



   Speed
10% 50% 95% 98%
Axway speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
Bitdefender speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
ESET speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
FortiMail speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
IBM speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
Kaspersky for Exchange speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
Kaspersky LMS speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
Libra Esva speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
Spamhaus DQS speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
Spin speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-YELLOW.jpg speed-colour-blobs-YELLOW.jpg
ZEROSPAM speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg speed-colour-blobs-GREEN.jpg
speed-colour-blobs-GREEN.jpg 0-30 seconds speed-colour-blobs-YELLOW.jpg 30 seconds to two minutes speed-colour-blobs-ORANGE.jpg two minutes to 10 minutes speed-colour-blobs-RED.jpg more than 10 minutes


(Please refer to the text for full product names.)



Products ranked by final score
FortiMail 99.95
ESET 99.95
IBM 99.93
Bitdefender 99.92
Kaspersky LMS 99.89
Kasperksy for Exchange 99.89
Spin 99.84
Libra Esva 99.76
Spamhaus DQS 99.34
Axway 99.31
ZEROSPAM 99.18

(Please refer to the text for full product names.)



Hosted solutions Anti-malware IPv6 DKIM SPF DMARC Multiple MX-records Multiple locations
Spin ClamAV; proprietary
ZEROSPAM ClamAV

(Please refer to the text for full product names.)



Local solutions Anti-malware IPv6 DKIM SPF DMARC Interface
CLI GUI Web GUI API
Axway Kaspersky, McAfee
Bitdefender Bitdefender
ESET ESET Threatsense
FortiMail Fortinet
IBM Sophos; IBM Remote Malware Detection
Kaspersky for Exchange Kaspersky Lab
Kaspersky LMS Kaspersky Lab    √
Libra Esva ClamAV; others optional
Spamhaus DQS Optional

(Please refer to the text for full product names.)







Appendix: set-up, methodology and email corpora

The full VBSpam test methodology can be found at https://www.virusbulletin.com/testing/vbspam/vbspam-methodology/.

The test ran for 16 days, from 12am on 9 February to 12am on 25 February 2019.

The test corpus consisted of 192,735 emails. 187,308 of these were spam, 39,931 of which were provided by Project Honey Pot, with the remaining 147,377 spam emails provided by Abusix. There were 5,226 legitimate emails ('ham') and 201 newsletters, a category that includes various kinds of commercial and non-commercial opt-in mailings.

181 emails in the spam corpus were considered 'unwanted' (see the June 2018 report) and were included with a weight of 0.2; this explains the non‑integer numbers in some of the tables.

Moreover, 229 emails from the spam corpus were found to contain a malicious attachment while 343 contained a link to a phishing or malware site; though we report separate performance metrics on these corpora, it should be noted that these emails were also counted as part of the spam corpus.

Emails were sent to the products in real time and in parallel. Though products received the email from a fixed IP address, all products had been set up to read the original sender's IP address as well as the EHLO/HELO domain sent during the SMTP transaction, either from the email headers or through an optional XCLIENT SMTP command4. Consequently, products were able to filter email in an environment that was very close to one in which they would be deployed in the real world.

For those products running in our lab, we ran them as virtual machines on a VMware ESXi cluster. As different products have different hardware requirements – not to mention those running on their own hardware, or those running in the cloud – there is little point comparing the memory, processing power or hardware the products were provided with; we followed the developers' requirements and note that the amount of email we receive is representative of that received by a small organization.

Although we stress that different customers have different needs and priorities, and thus different preferences when it comes to the ideal ratio of false positives to false negatives, we created a one-dimensional ‘final score’ to compare products. This is defined as the spam catch (SC) rate minus five times the weighted false positive (WFP) rate. The WFP rate is defined as the false positive rate of the ham and newsletter corpora taken together, with emails from the latter corpus having a weight of 0.2:

WFP rate = (#false positives + 0.2 * min(#newsletter false positives , 0.2 * #newsletters)) / (#ham + 0.2 * #newsletters)

while in the spam catch rate (SC), emails considered ‘unwanted’ (see above) are included with a weight of 0.2.

The final score is then defined as:

Final score = SC - (5 x WFP)

In addition, for each product, we measure how long it takes to deliver emails from the ham corpus (excluding false positives) and, after ordering these emails by this time, we colour-code the emails at the 10th, 50th, 95th and 98th percentiles:

YELLOW (yellow) = 30 seconds to two minutes



Products earn VBSpam certification if the value of the final score is at least 98 and the ‘delivery speed colours’ at 10 and 50 per cent are green or yellow and that at 95 per cent is green, yellow or orange.

Meanwhile, products that combine a spam catch rate of 99.5% or higher with a lack of false positives, no more than 2.5% false positives among the newsletters and ‘delivery speed colours’ of green at 10 and 50 per cent and green or yellow at 95 and 98 per cent earn a VBSpam+ award.



Footnotes

1 While it is, in principle, possible for an email security product to open all links, doing so has a number of unwanted implications for the recipient; hence products tend to be reluctant to do so.

2 https://www.virusbulletin.com/blog/.

3 Abusix is also the provider of this feed. The feed is sent in real time and Abusix does not have advance knowledge of what emails are part of it.

4 http://www.postfix.org/XCLIENT_README.html.

Download PDF




Latest reviews:

VB100 Certification Report

The August 2019 report details the VB100 certification of 37 anti‑malware products from 34 different vendors tested during July and August 2019.

VBWeb Comparative Review - Summer 2019

The VBWeb tests measure the performance of web security products against a wide range of live web threats, this time also including phishing threats.

VB100 certification report

The June 2019 VB100 report details the VB100 certification of 34 anti‑malware products from 31 different vendors tested during May and June 2019.

VBSpam comparative review - June 2019

In the June 2019 VBSpam test 12 full email security solutions and three blacklists of various kinds are put through their paces, resulting in 12 VBSpam certifications and six VBSpam+ awards.

VBWeb Comparative Review - Spring 2019

Most organizations use web security products to minimize the risk of malware making it onto the network - the VBWeb tests measure the performance of such web security products against a wide range of live web threats.

We have placed cookies on your device in order to improve the functionality of this site, as outlined in our cookies policy. However, you may delete and block all cookies from this site and your use of the site will be unaffected. By continuing to browse this site, you are agreeing to Virus Bulletin's use of data as outlined in our privacy policy.
